DESCRIPTION
1-channel real-time online-offline programmable digital current data logger for precise voltage monitoring in industrial automation, electrical testing, R&D labs, and validation environments. Equipped with 30+ high-performance features for seamless monitoring, logging, and calibration management.
WARRANTY & POST-SALES SERVICE
-
5-year MIIG-warranty for long-term reliability
-
Replaceable sensor element for durability in harsh conditions
-
Component-level repair and replacement for extended product life
ONLINE DEVICE UPGRADATION & REPAIR
-
Dynamic DFU chip for online firmware updates and repairs
-
Eliminates the need for unit returns, saving time and cost
CALIBRATION MANAGEMENT
-
10-point drift correction calibration with complete graph-based accuracy
-
Automatic calibration due date reminders
-
Secure, non-editable calibration value storage
ACCURACY
Voltage range options:
-
Accuracy: ±0.02 VDC, range: 0 to 10.00 VDC, resolution: 0.01 VDC
-
Accuracy: ±0.005 VDC, range: 0 to 1 / 3.6 / 5 VDC, resolution: 0.001 VDC
-
Voltage data defined within -9999 to 9999 range
DISPLAY MANAGEMENT
-
Display of current value, date, and time
-
28mm (H) x 30mm (W) large LCD for clear visibility
-
Min-max-average values displayed for all parameters
-
Customizable display to show or hide selected parameters
-
Full-screen low battery alarm notification
-
FIFO display of last 15 alarms
-
Multi-alarm icon display for quick response
-
Data refresh rate: every 5 seconds
ALARM MANAGEMENT
-
2 pre-alarms + 2 real alarms per parameter
-
Audible and visual alarms for real-time alerts
-
Judgement time alarm function to reduce false alerts
-
Online alarm notifications via mobile and PC applications
-
Last 15 alarms stored in FIFO format for quick review
MEMORY MANAGEMENT
-
1-channel logger with 40,000 data point memory
-
Adjustable data logging interval from 1 second to 24 hours
REAL-TIME MONITORING VIA SOFTWARE & MOBILE APPLICATIONS
-
Live monitoring of current values, battery status, and alarms
-
MIIG-BLUE mobile app (password-protected)
-
BLUE-DESK PC software (password-protected)
-
21 CFR PART II compliant software (upcoming)
REPORT MANAGEMENT
-
Generate standard tabular, alarm, and graph reports in PDF or CSV format
-
Supports single-device and multi-device reports (up to 50 devices) via BLUE-DESK
AUDIT SUPPORT TOOL
-
Protection against false calibration certificates
-
Password protection on device, mobile app, and PC software
-
Customizable display for compliance with GMP and SOP regulations
BULK OPERATION (OPTIONAL)
-
BLUE-DOCK interface enables mass programming, data download, and monitoring of up to 50 devices
ACCESSORIES
-
Magnetic ring for easy, screwless mounting
-
Compatible with industrial-grade mounting environments
