DESCRIPTION
The High-Precision Humidity & Temperature Calibration Chamber ensures fast, stable, and accurate calibration for sensors. Designed for laboratory use, it features ultra-stable climatic control, multiple probe mounts, and an intuitive touchscreen interface. Available in 2-litre and 20-litre models, it supports FDA-compliant software for seamless calibration.
TECHNICAL SPECIFICATIONS
Chamber Volume
-
2L Model: 1.5L working volume, 13 kg, mounts up to 6 probes
-
20L Model: 17L working volume, 37 kg, mounts up to 19 probes
Climatic Performance
-
Humidity Stability: <±0.1 %RH (5–95 %RH)
-
Temperature Stability: <±0.01 °C (23–50 °C)
-
Fast stabilization times (5–35 min depending on model & conditions)
Control System
-
Mixed flow system with desiccant dryer & piezoelectric humidifier
-
Peltier thermoelectric cooling, radial mixing fan
-
Embedded PID controller & touchscreen interface
Additional Features
-
20 user-programmable profiles with 200 set-points
-
Integrated Rotronic HW5 software (FDA 21 CFR Part 11 compliant)
-
USB ports, real-time desiccant monitoring, low/high water alarms
-
Optional range extension, AutoCal, remote API
Power & Enclosure
-
Input: 110–240 VAC, 50/60 Hz | Power: 3A (240V), 6A (110V)
-
Powder-coated aluminum & steel, IP-rated protection
APPLICATION AREAS
-
Sensor calibration labs
-
Pharmaceutical & medical QA/QC
-
Environmental monitoring
