MIIGO - FTS07 Hot Wire Air Velocity Transmitter for Probe Type

DESCRIPTION

This compact Air Velocity Sensor offers accurate measurement up to 10 or 20 m/s, making it an ideal solution for HVAC process monitoring, cleanroom airflow control, and laminar flow environments. Engineered with high stability, repeatability, and angle tolerance, this sensor provides excellent performance at an economical cost—ensuring high cost-to-performance (C/P) value.

TECHNICAL SPECIFICATIONS

MEASUREMENT PARAMETERS

• Measuring Range: 10 m/s or 20 m/s

• Minimum Measuring Range: 0.2 m/s

• Accuracy (at +25°C): ±5% F.S.

• Angular Dependence: <3% of measuring range (installation angle < 10°)

• Response Time: t90 ≤ 1 second

OUTPUT & CONNECTIVITY

• Output Signal: DC 0...10 V

• Signal Connection: 3-wire voltage output

• Load Resistance: >10 KΩ

ENVIRONMENT

• Measuring Medium: Air

• Operating Temperature: 15...35°C

• Operating Humidity: 10...90% RH (non-condensing)

• Storage Temperature: -10...+60°C

ELECTRICAL SPECIFICATIONS

• Power Supply: DC 24 V ±20%

• Current Consumption: <70 mA

• Overvoltage Protection: DC <35 V

• Electrical Connection: PVC cable, 0.32 mm² x 3C

INSTALLATION & PROTECTION

• Installation Method: Fixed seat or flange mount

• Protection Rating: IP20

• Electrical Protections:

  • Reverse polarity

  • Over-voltage

MATERIAL & DIMENSIONS

• Housing: PC fire-proof (UL94V-2)

• Filter: PC with glass fiber

• Cable: PVC

• Weight: 25 g (without cable)

CERTIFICATION

• CE Certified

APPLICATION AREAS

• HVAC System Airflow Monitoring

• Cleanroom & Environmental Control

• Laminar Flow Monitoring
