DESCRIPTION
The EE212 Humidity & Temperature Sensor is a versatile and reliable solution for wall, duct, and outdoor installations. It provides accurate RH and temperature measurement along with calculated dew point, absolute humidity, and mixing ratio. With two analogue outputs, a Modbus RTU interface, and an optional graphic display, it is ideal for industrial and commercial climate monitoring.
TECHNICAL SPECIFICATIONS
MEASUREMENT PARAMETERS
-
Humidity Range: 0…100% RH
Humidity Accuracy:
-
At 23 °C: ±(1.5+0.005*mv)% RH
-
From -15 to 60 °C: ±(1.8+0.007*mv)% RH
-
For -40 to -15 °C: Additional uncertainty ±0.125 %RH/°C
-
Temperature Range: -40…60 °C (-40…160 °F)
-
Temperature Accuracy: ±0.3 °C (0.54°F)
OUTPUT & CONNECTIVITY
-
Analogue Outputs: 0-5V / 10V or 0/4-20mA
-
Digital Output: Modbus RTU
-
Power Supply: 24V AC/DC
KEY FEATURES
-
Available for wall, duct, and outdoor use
-
Proprietary coated sensor for long-term stability
-
Easy on-site replacement of sensing module
-
Encapsulated electronics for protection against condensation
-
Configurable via EE-PCS software & adapter cable
