DESCRIPTION
The EE210 Humidity & Temperature Sensor delivers high accuracy and long-term stability, making it ideal for harsh and aggressive environments. Equipped with encapsulated measurement electronics and an E+E proprietary-coated humidity sensor, it ensures reliable performance in challenging conditions. The sensor also calculates key physical parameters, including dew point, frost point, absolute humidity, and enthalpy, offering versatile climate monitoring solutions.
TECHNICAL SPECIFICATIONS
MEASUREMENT PARAMETERS
-
Humidity Range: 0…100% RH
-
Humidity Accuracy:
-15 to 40 °C <90% RH: ±(1.3+0.003mv)% RH
-15 to 40 °C >90% RH: ±2.3% RH
-40 to 60 °C: ±(1.5+0.015mv)% RH
-
Temperature Range: -40…80 °C (-40…176 °F)
-
Temperature Accuracy: ±0.2 °C (0.34°F)
OUTPUT & CONNECTIVITY
-
Analogue Outputs: 0-5V / 10V or 4-20mA
-
Digital Output: Modbus RTU
-
Power Supply: 24V AC/DC
APPLICATION AREAS
-
Agriculture & Greenhouses
-
Hatcheries & Incubators
-
Storage Rooms & Cold Chambers
-
Swimming Halls & High-Humidity Environments
-
Industrial & Process Monitoring
