HC2A-IE102 Stainless Steel Humidity Temperature Sensor​

DESCRIPTION

The HC2A-IE02-G/NPT Premium Stainless Steel %RH-Temp Sensor is a high-performance solution designed for pressurized environments up to 100 bar. Built with DIN 1.4301 stainless steel housing, it ensures precision, durability, and resistance to mechanical and chemical stress, making it ideal for critical industrial applications.

KEY FEATURES & TECHNICAL SPECIFICATIONS

• Accuracy:
  • ±0.8 %RH humidity accuracy
  • ±0.1°C temperature accuracy
• Measurement Range:
  • Temperature: -100°C to +200°C
  • Humidity: 0 to 100% RH
• Pressure Compatibility:
  • Designed for pressurized conditions up to 100 bar
• Probe Size:
  • 148 mm stainless steel probe
• Material of Construction:
  • High-grade Stainless Steel (DIN 1.4301) for extreme durability and corrosion resistance
• Cable Length:
  • 2-meter high-quality connecting cable
• Output Signal:
  • 0 – 1 VDC analog output for %RH and Temperature
• Power Supply:
  • 3.0 to 5.0 VDC for flexible integration

APPLICATION AREAS

• High-Pressure Industrial Systems
• Chemical and Petrochemical Industries
• Compressed Air Monitoring
• Pharmaceutical Manufacturing
• Environmental Test Chambers
